Description
Item Attributes: Operating Mode: ElectricVoltage: 12 VPressure [bar]: 2.5 barPressure pipe connector Ø: 11 mmSuction pipe connector Ø: 10.5 mmFlow rate: 432 l/hHousing Diameter: 35 mmPump Type: Mono PumpAssembly by qualified personnel required!Application: HELLA washer water pumps have been developed for two different applications: for windscreen washers and for headlight washers. Pumps for windscreen cleaning systems are required for on-demand cleaning of windscreens. Pumps for headlight washers require more energy than pumps for windscreen washers because the headlights are cleaned with a water jet under higher pressure. To adapt to the piping system a connection is used that enables simple quick and safe adjustment of the hose arrangement. Thanks to its special know-how and high quality standards HELLA is a leader in the segment of windscreen and headlight cleaning systems. Structure and function: The windscreen washer pump has a water intake and 2x water outlets that can be used alternately. Depending on the direction of rotation of the DC motor one or the other water outlet is used. The direction of rotation of the DC motor depends on the polarity of the connections. The pump can be controlled via the Front Control Module (FCM) for example.OE references: ARTEGA 80-922-003-00; BUCHER 7020917; HYMER 1280760-00; HYMER 1475125; HYMER 1475125-00; HYMER 8020333; LAIKA 1280760-00; PAGANI CM15.195.10Water Pump window cleaning;HELLA;Electric;12V;25bar;Mono Pump;105mm;11mm;432l/h;35mm;
